The Helimover™ is an electric tug / tow cart / trolley designed for Robinson R22, R44 and R66 helicopters. It provides a simple and economic means of ground handling for Robinson helicopter owners and operators.

• Costs less than other tugs
• Robustly built and easy to use
• Exceptional power and manoeuvrability
• Compact design

EASY TOW BALL CAPTURE

A clever locking balanced lever system moves the ball hitch socket upwards to capture, and lock onto, the Robinson tow ball.

SAFETY FEATURES

• Automatic electronic parking brake is engaged when power is on and the throttle is released.
• Helimover operation is prevented if the power is switched on whilst the throttle lever is pressed
• Helimover will not move if battery charging is in progress
• The Ball Hitch locks onto the Robinson tow ball to prevent disengagement
• Key operated security isolation switch
• Soft start and stop
• LED illuminated tow ball line up aid

TECHNICAL SPECIFICATIONS

Product Description: The Helimover™ is an electric tug designed for Robinson R22, R44 and R66 helicopters. It provides a simple and economic means of ground handling for Robinson owners and operators.

Motor: Permanent magnet 24v DC 300w

Gear-Box Reduction: 25:1

Drive Chain Reduction: 2.5:1

Avg Torque at Drive Wheels: 100 lbs/ft (150NM)

Batteries: 2 x 12V sealed, valve regulated Lead Acid (maintenance free)

Battery Charger: 110 or 220 / 240VAC

Motor Control Unit: Solid state, pre-programmed.

Tyres: 2 x 4.10/3.50-4 with inner tubes, max pressure 50 psi optimum 30 psi. Robinson ground handling wheels should be 60 psi

Lift Height: (Ground to Top of Ball Socket)
Down: 14.37” (366mm)
Up: 18.87” (480mm)
Weight: 172lbs (78 kgs)

Dimensions: (In shipping configuration)
Length: 34 1/4” (870mm)
Width: 27 1/8” (870mm)
Height: 18 1/2” (457mm)

Warranty: Product is warranted against all defects in materials and manufacture for 1 year from date of purchase
